ICS TRIPLEX T9852 (9852) 8-Channel Dual Digital Output Termination Assembly in stock
ICS TRIPLEX T9852 (short name 9852) is dual redundant digital output termination assembly for AADvance SIL3 safety instrumented system. It is matched with T9451 digital output module, acting as the field wiring interface between safety I/O card and field actuators such as solenoid valves and shutdown valves. It accepts dual 24VDC field power supply and provides built-in fuses for overcurrent protection.
This termination unit adopts pluggable screw terminal blocks for convenient wiring and maintenance. It supports dual redundant signal path, preventing single power failure from causing safety loop loss. It complies with IEC 61508 SIL3 safety certification. It is discontinued legacy hardware, supplied as surplus or refurbished spare parts for maintenance and retrofit of existing AADvance safety systems.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | ICS TRIPLEX (Rockwell Automation) |
| 2 | Model | T9852 (9852) |
| 3 | Module Type | Dual Digital Output Termination Assembly (TA) |
| 4 | Compatible System | AADvance SIS, paired with T9451 digital output module |
| 5 | Channels & Power | 8 output channels, dual 24VDC field power input |
| 6 | Protection | Built-in 10A replaceable fuses for each power channel |
| 7 | Operating Temperature | -40℃ ~ +70℃ |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Field wiring terminal interface for T9451 DO module to connect solenoid valves and shutdown actuators |
| 2 | Dual redundant 24VDC power input design to improve safety loop availability |
| 3 | Built-in replaceable fuses to isolate field short-circuit faults and protect I/O modules |
| 4 | Pluggable screw terminal blocks for fast wiring and hot-swap maintenance |
| 5 | Signal routing for dual redundant safety output architecture for ESD protection |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Oil & gas refinery and pipeline SIL3 emergency shutdown system(ESD) |
| 2 | Power plant boiler and turbine safety trip valve control cabinet |
| 3 | Chemical plant reactor fire & gas protection safety instrumented system |
| 4 | BMS burner management system and high-risk process safety interlock |
| 5 | AADvance safety system spare replacement and system retrofit project |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What is ICS TRIPLEX T9852 (9852)? A:It is 8-channel dual digital output termination assembly for AADvance SIL3 SIS. It works with T9451 DO module, provides field wiring terminals, dual 24VDC power input and fuse protection for safety valve actuators. |
| 2 | Q:What is difference between T9851 and T9852? A:T9851 is simplex digital output termination assembly. T9852 is dual redundant version, supporting dual power supply and dual channel architecture for higher safety availability. |
| 3 | Q:Is T9852 still in production? A:ICS Triplex AADvance series T9852 has been discontinued. Available stock is surplus or refurbished spare parts for maintenance of legacy SIL3 safety instrumented systems. |
