Bently Nevada 3500/22M 288055-01 Transient Data Interface Module in stock
Bently Nevada 3500/22M 288055-01 is a transient data interface module for the 3500 machinery protection system. It acquires high-speed waveform and transient vibration data for rotating machinery fault analysis and event recording.
This module supports waveform storage and Ethernet data transmission to analysis workstations. It serves as legacy spare parts for turbine TSI systems in power plants and petrochemical industries for maintenance replacement.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | Bently Nevada (Baker Hughes) |
| 2 | Model | 3500/22M 288055-01 |
| 3 | Module Type | Transient Data Interface Module |
| 4 | Communication | Ethernet port for waveform data upload |
| 5 | Power Supply | Rack backplane powered |
| 6 | Working Temperature | -30 ~ +65°C |
| 7 | Status | Legacy spare for 3500 TSI rack |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Collect high-speed transient waveform data from all 3500 monitoring modules |
| 2 | Automatically capture and store waveform snapshots on alarm or trip events |
| 3 | Transmit orbit, spectrum and time-base waveform data via Ethernet |
| 4 | Support post-trip analysis for root cause diagnosis of rotating equipment |
| 5 | Front panel LED indicators for module health and network status |
Application Scenarios
| No. | Application |
|---|---|
| 1 | 3500 series TSI machinery protection monitoring rack |
| 2 | Steam turbine and gas turbine vibration transient monitoring |
| 3 | Thermal power plant turbine trip fault investigation |
| 4 | Oil & gas compressor rotating equipment condition diagnosis |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q: What is Bently Nevada 3500/22M 288055-01? A: It is transient data interface module for 3500 rack to capture high-speed vibration waveform data for equipment fault analysis. |
| 2 | Q: What is the difference between 288055-01 and 146031-01? A: They are different part revisions of 3500/22M, both perform the same transient data capture function. |
| 3 | Q: Does it work independently? A: No, it needs to cooperate with 3500/20 rack interface module for full system operation. |
