ABB 216EA62 1MRB150083R1/F 1MRB178066R1/F Analog Output Module in stock
ABB 216EA62 (1MRB150083R1/F,1MRB178066R1/F) is an analog output module for ABB Advant Master DCS system. It converts digital control commands from the DCS controller into standard analog signals to regulate field actuators such as control valves and variable speed drives.
This module adopts isolated channel design to reduce field interference. It supports 4-20mA analog signal output and built-in diagnostic function. It is a discontinued legacy spare, used for maintenance and replacement of old Advant Master DCS control racks.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | ABB |
| 2 | Model | 216EA62, 1MRB150083R1/F, 1MRB178066R1/F |
| 3 | Module Type | Analog Output Module |
| 4 | System Platform | ABB Advant Master DCS |
| 5 | Output Signal | 4-20mA |
| 6 | Isolation | Channel galvanic isolation |
| 7 | Mounting | DCS rack mount |
| 8 | Operating Temperature | 0℃ ~ +60℃ |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Receive digital control values from Advant Master DCS controller |
| 2 | Convert digital signals to 4-20mA analog output to drive field actuators |
| 3 | Galvanic isolation to block ground loop and suppress electromagnetic interference |
| 4 | Channel self-diagnosis, detect circuit faults and send alarm to controller |
| 5 | Overload and short-circuit protection to prevent module damage from field faults |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Power plant ABB Advant Master DCS control cabinet |
| 2 | Petrochemical, oil & gas continuous process regulating control |
| 3 | Pulp & paper, metallurgy industrial process valve regulation |
| 4 | 4-20mA control signal output for control valves and actuators |
| 5 | Legacy ABB Advant DCS spare parts replacement and overhaul project |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What is ABB 216EA62 1MRB150083R1/F 1MRB178066R1/F? A:It is an analog output module for ABB Advant Master DCS. It converts digital control commands into 4-20mA analog signals to control field regulating valves and actuators. |
| 2 | Q:What signal does this AO module output? A:Standard 4-20mA analog signal, widely used for continuous adjustment of industrial field actuators. |
| 3 | Q:Which DCS system does this module belong to? A:It belongs to ABB Advant Master DCS system, installed in Advant rack and matched with Advant series controllers. |
