GE IC8008SI228RD2-EE SSI Encoder Interface Module

GE IC8008SI228RD2-EE is a high-precision SSI synchronous serial encoder interface module belonging to GE IC800 series control system. It is used to collect position data from absolute SSI encoders and transmit position feedback signals to the main controller for motion control.

This module supports dual independent SSI encoder channels with high resolution and fast data update rate. It has strong anti-interference performance, widely adopted in precision motion control projects and serves as spare replacement parts for industrial automation equipment maintenance and retrofit.

Data Parameters

• 1. Brand: GE.

• 2. Model: IC8008SI228RD2-EE.

• 3. Product Type: SSI Encoder Interface Module.

• 4. Encoder Channel: Dual independent SSI channels.

• 5. Resolution: Up to 24-bit position resolution.

• 6. Data Update Rate: 1kHz high speed data sampling.

• 7. Power Supply: 24V DC ±10%.

• 8. Operating Temperature: -25℃ ~ +70℃.

• 9. Mounting: Chassis backplane installation.

• 10. Vibration Resistance: 5g @10~500Hz.

Core Functions

• 1. Receive and decode synchronous serial data from absolute SSI encoders.

• 2. Real-time high precision position acquisition for motion control and position monitoring.

• 3. Dual channel design supports redundant encoder signal collection for safety-critical applications.

• 4. Built-in signal diagnosis function to detect encoder cable fault and signal loss.

• 5. Transmit position data to GE main controller through backplane bus communication.

Application Scenarios

• 1. CNC machine tools and automated production line precision position control system.

• 2. Packaging machinery, printing equipment high-speed motion feedback control cabinet.

• 3. Metallurgical rolling mill and lifting equipment absolute position monitoring system.

• 4. Oil & gas industry valve actuator position feedback and interlock control.

• 5. GE IC800 series automation system spare parts replacement and upgrade project.

FAQ

• 1. Q: What is GE IC8008SI228RD2-EE?
      A: It is an SSI encoder interface module for GE IC800 series system, used for collecting absolute encoder position signal for motion control.

• 2. Q: How many SSI encoder channels does this module have?
      A: It has two independent SSI channels and can connect two absolute encoders simultaneously.

• 3. Q: What is the maximum position resolution supported?
      A: It supports up to 24-bit high resolution position data acquisition for precision automation applications.
