PROSOFT MVI56-MNETR Modbus TCP Communication Module in stock
PROSOFT MVI56-MNETR is an in-chassis Modbus TCP client/server communication module designed for Allen‑Bradley ControlLogix 1756 rack. It adopts reduced data block architecture, realizing high-efficiency data exchange between ControlLogix PAC and Modbus TCP field instruments, drives and third-party controllers.
This module supports 10/100Mbps Ethernet RJ45 interface, acts as both Modbus TCP client and server. It features on-board web server for remote configuration and diagnosis, and communicates with ControlLogix CPU through backplane bus, widely used for protocol conversion in industrial process automation.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | PROSOFT Technology |
| 2 | Model | MVI56-MNETR |
| 3 | Module Type | Modbus TCP Client/Server Communication Module |
| 4 | Compatible Rack | Allen-Bradley ControlLogix 1756 chassis |
| 5 | Ethernet Interface | 10/100 Base-T, RJ45 |
| 6 | Power Consumption | 800mA @ 5VDC, 3mA @ 24VDC |
| 7 | Operating Temperature | -20℃ ~ +60℃ |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Bi-directional Modbus TCP client/server communication for protocol conversion |
| 2 | Reduced data block design to decrease backplane data transmission load |
| 3 | Onboard web server for remote configuration, monitoring and fault diagnosis |
| 4 | Data exchange with ControlLogix CPU via 1756 backplane bus |
| 5 | Support Modbus holding register, input register, coil and discrete input access |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Power plant auxiliary control system protocol conversion project |
| 2 | Oil & gas, chemical industry ControlLogix and Modbus device interconnection |
| 3 | Water treatment plant PLC and Modbus TCP instrument data acquisition |
| 4 | Factory automation production line multi-brand device networking integration |
| 5 | Legacy ControlLogix system spare parts replacement and retrofit |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What PLC platform is MVI56-MNETR for? A:It is an in-chassis module for Allen‑Bradley ControlLogix 1756 series PAC. |
| 2 | Q:What protocol does it support? A:Modbus TCP, working as both Modbus TCP client and server. |
| 3 | Q:What is the advantage of reduced data block? A:It reduces backplane data volume and optimizes communication performance for remote rack application. |
