KONGSBERG MRU-E-JB1 MRU-E Junction Box for Motion Reference Unit in stock
KONGSBERG MRU-E-JB1 is a dedicated marine junction box for MRU-E series motion reference unit (MRU). It serves as the signal interface terminal box, connecting MRU-E motion sensor with ship control system, power supply and serial communication lines, responsible for signal routing and overvoltage protection in harsh offshore environments.
This JB1 junction box is IP65 marine enclosure, compatible with 4th generation MRU-E and backward compatible with 5th generation MRU sensors, but only supports serial communication (COM2 and analog outputs are unavailable). It is obsolete legacy hardware, widely supplied as surplus or refurbished spare parts for offshore vessel and platform motion monitoring system maintenance.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | KONGSBERG (Seatex) |
| 2 | Model | MRU-E-JB1 |
| 3 | Module Type | MRU-E Junction Box (Signal Terminal Box) |
| 4 | Protection Class | IP65 marine grade enclosure |
| 5 | Supported Communication | Serial communication only (RS232/RS422) |
| 6 | Compatible Sensor | 4th Gen MRU-E, backward compatible with 5th Gen MRU |
| 7 | Operating Temperature | -25℃ ~ +70℃ |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Provide wiring terminal interface between MRU-E motion sensor and vessel control system |
| 2 | Route power supply and serial motion data signals for MRU sensor unit |
| 3 | Built-in surge and overvoltage protection for marine salt spray and interference environment |
| 4 | Transmit roll, pitch and heave motion data from MRU sensor to dynamic positioning system |
| 5 | IP65 rugged housing protects internal circuits against moisture, dust and salt corrosion |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Offshore platform dynamic positioning (DP) system motion measurement |
| 2 | Helideck monitoring system for offshore oil & gas vessels |
| 3 | Marine survey vessel echo sounder and sonar heave compensation |
| 4 | Offshore crane motion compensation and vessel attitude monitoring |
| 5 | Legacy Kongsberg MRU system spare parts replacement and retrofit |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What is KONGSBERG MRU-E-JB1? A:It is marine junction box for Kongsberg MRU-E motion reference unit, used for power and serial signal wiring, providing IP65 protection and signal protection for offshore motion measurement system. |
| 2 | Q:Can MRU-E-JB1 support Ethernet communication? A:No, JB1 only supports serial communication. COM2 and analog signal outputs are not available with this junction box. |
| 3 | Q:Is this junction box still in production? A:MRU-E-JB1 is obsolete, replaced by JB3 junction box. Stock is mainly surplus and refurbished spare parts for existing marine system maintenance. |
