GE IS200SDIIH1ADB Mark VIe Digital Input Terminal Board in stock
GE IS200SDIIH1ADB is a high-speed digital input terminal board for GE Mark VIe turbine control DCS system. It provides galvanic isolated digital signal acquisition and high-precision SOE sequence of events timestamping for breaker, relay and valve limit switch signals.
This board features multi isolated input channels, on-board signal filtering and status LED indicators. It communicates with the main turbine controller through rack backplane bus. It is discontinued legacy spare widely used for gas turbine and steam turbine control system maintenance replacement in power and oil & gas industries.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | GE |
| 2 | Model | IS200SDIIH1ADB |
| 3 | Module Type | Mark VIe Digital Input Terminal Board |
| 4 | Applicable System | GE Mark VIe Turbine Control DCS |
| 5 | Signal Type | Discrete digital input, dry contact |
| 6 | Function | Digital signal acquisition + SOE event timestamping |
| 7 | Isolation | Galvanic channel group isolation |
| 8 | Communication | Rack backplane bus |
| 9 | Operation Temperature | -40℃ ~ +85℃ |
| 10 | Status | Discontinued legacy DCS spare part |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Collect field discrete digital signals from limit switches, circuit breakers and relay contact status. |
| 2 | High precision SOE event timestamping to record the exact time of digital state change for fault analysis. |
| 3 | Galvanic isolation and built-in noise filtering to suppress industrial electromagnetic interference. |
| 4 | Transmit processed digital data to Mark VIe main controller via rack backplane bus. |
| 5 | Onboard LED indicators to display channel status, power supply and communication health. |
Application Scenarios
| No. | Application |
|---|---|
| 1 | GE Mark VIe gas turbine and steam turbine control & protection system for power plants |
| 2 | Oil & gas pipeline and compressor unit safety interlock and status monitoring system |
| 3 | Power plant SOE event recording and fault post-mortem analysis system |
| 4 | Legacy Mark VIe turbine control system spare replacement and on-site maintenance |
