GE DS200DTBCG1AAA Contact Output Terminal Board
GE DS200DTBCG1AAA is a contact output terminal board for GE Mark V Speedtronic gas turbine control system. It converts control signals from the main turbine controller into dry contact relay outputs to drive field solenoid valves, relays and auxiliary actuators.
This board is equipped with terminal blocks and bayonet connectors for rack wiring. It provides dry contact output channels for turbine trip, valve control and auxiliary equipment logic. It is an obsolete legacy hardware, commonly used as spare replacement parts for existing power plant Mark V turbine control cabinets.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | GE General Electric |
| 2 | Model | DS200DTBCG1AAA |
| 3 | Module Type | Contact Output Terminal Board |
| 4 | Compatible System | Mark V Speedtronic Gas Turbine Control System |
| 5 | Output Type | Dry contact relay output, rated up to 125VDC |
| 6 | Connectors | 2 × 3-wire bayonet connectors, 1 × 2-wire bayonet connector |
| 7 | Operating Temperature | 0℃ ~ +60℃ |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Receive logic commands from Mark V main controller and output dry contact relay signals |
| 2 | Drive field solenoid valves, auxiliary relays and turbine interlock actuators |
| 3 | Terminal block termination for convenient field wiring, inspection and maintenance |
| 4 | Signal isolation between turbine controller and high-current field load equipment |
| 5 | Execute turbine trip, valve control and auxiliary equipment on/off logic output |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Power plant Mark V gas/steam turbine control cabinet output termination |
| 2 | Combined cycle unit turbine protection trip and valve drive control |
| 3 | Oil & gas power generation plant turbine auxiliary equipment logic control |
| 4 | Heavy industry large turbine safety interlock and actuation control |
| 5 | Legacy Mark V control system spare parts replacement and maintenance |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What is GE DS200DTBCG1AAA? A:It is contact output terminal board for Mark V Speedtronic turbine control system, providing dry relay contact outputs for field actuators. |
| 2 | Q:What is the difference between DS200DTBAG1AAA and DS200DTBCG1AAA? A:DTBAG1AAA is contact input board; DTBCG1AAA is contact output relay terminal board. |
| 3 | Q:Is this board still manufactured? A:No, GE discontinued production, only surplus and refurbished spare parts available for legacy system maintenance. |
