Products Description
Product Overview
ABB 3BHL000390P0104 5SHX1960L0004 is a high-power IGCT integrated gate commutated thyristor module for ABB medium voltage drives and power conversion systems. It combines high-current switching capability with fast gate control to realize reliable high-voltage power conversion for industrial power equipment.
This module adopts ceramic packaging and high thermal conductivity design, with overcurrent, overheating and short-circuit protection. It is widely used as spare parts for medium voltage frequency converters, static var compensators and power plant power conversion cabinets.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Main Specifications
Brand: ABB; Model: 3BHL000390P0104 / 5SHX1960L0004; Type: IGCT Power Semiconductor Module
Compatible System: ABB medium voltage inverter, power conversion and reactive power compensation system
Core Functions: High voltage large current switching, power conversion, over-temperature and over-current protection
Package: Ceramic sealed package; Cooling: Air cooling / liquid cooling optional
Operating Temperature: -40℃ ~ +85℃; Installation: Screw fixed mounting
Feature: Fast switching speed, high surge current resistance, high reliability power semiconductor
Supply Status: Original ABB spare IGCT module for medium voltage power equipment maintenance
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Core Functions
Realize high-power switching control for medium voltage power conversion system, convert AC and DC power.
Integrated gate commutated thyristor structure for fast turn-off and stable operation under heavy load conditions
Built-in thermal detection and overcurrent protection mechanism to prevent module damage from abnormal working conditions.
Ceramic packaging structure reduces thermal resistance and improves heat dissipation performance under continuous high current operation.
Support series and parallel combination to expand voltage and current capacity for large power conversion equipment.
Standard mounting structure, convenient disassembly and replacement during medium voltage drive maintenance.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Application Scenarios
Power switching core component for ABB medium voltage inverters used in mining, water pump and fan drive systems.
Fault module replacement and routine maintenance of medium voltage power conversion cabinets and SVC reactive power compensation devices.
Power electronic system renovation for thermal power, hydropower and metallurgy heavy industry plants.
Emergency replacement for module failure to restore medium voltage drive and power conversion equipment operation.
Spare parts stocking for maintenance teams operating ABB medium voltage power electronics platforms.
Aftermarket spare supply for medium voltage converter overhaul and power quality improvement transformation projects.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
FAQ
Q: Can ABB 3BHL000390P0104 5SHX1960L0004 replace ordinary thyristor directly?
A: IGCT needs matching gate drive unit, cannot directly replace conventional SCR thyristor.
Q: What are typical IGCT module failure symptoms?
A: Module short circuit, overheating alarm, drive fault, power unit cannot output power.
Q: How to complete commissioning and diagnosis?
A: Check cooling system, tighten mounting torque, test gate drive signal, perform insulation and power-on test.
