Triconex MP3101 Redundant Main Processor Module

Triconex MP3101 is the redundant main processor module designed for Trident triple modular redundant safety instrumented system. It runs safety control logic, executes 2oo3 voting algorithm and handles data communication with I/O modules in the safety rack.

This module uses Motorola MPC860 32-bit CPU and integrates flash and dram memory for safety program storage. It supports hot-swap replacement and continuous hardware self-diagnosis, widely used as spare replacement for petrochemical, power and chemical safety control cabinet maintenance and upgrade projects.

Data Parameters

• 1. Brand: Triconex.

• 2. Model: MP3101.

• 3. Product Type: Redundant Main Processor Module.

• 4. System Architecture: Triple Modular Redundant (TMR, 2oo3 voting).

• 5. Safety Level: IEC 61508 SIL3 certified.

• 6. CPU: Motorola MPC860 32-bit 50MHz processor.

• 7. Memory: 6MB Flash, 16MB DRAM, 8KB NVRAM.

• 8. Power Supply: 24V DC, 19.2V ~ 30V DC operating range.

• 9. Feature: Support online hot swap replacement.

• 10. Compatible System: Triconex Trident TMR SIS safety rack system.

Core Functions

• 1. Execute safety logic program and perform 2-out-of-3 voting for all input and output signals.

• 2. Manage backplane data communication between processor and all I/O modules in the Trident rack.

• 3. Real-time hardware self-diagnosis to detect faults of CPU, memory and internal bus.

• 4. Support hot swap maintenance without stopping the running safety instrumented system.

• 5. Provide Ethernet and serial interfaces to connect TriStation, DCS and HMI monitoring systems.

Application Scenarios

• 1. Oil & gas industry ESD emergency shutdown system spare parts replacement.

• 2. Chemical plant reactor safety interlock control cabinet maintenance and retrofit.

• 3. Power plant boiler and turbine safety protection system renovation project.

• 4. Petrochemical refining SIS safety instrumented system spare parts inventory.

• 5. Legacy Triconex Trident TMR safety automation system overhaul and processor renewal.

FAQ

• 1. Q: What is Triconex MP3101?
      A: It is SIL3 redundant main processor module for Triconex Trident TMR safety instrumented SIS system.

• 2. Q: What system does MP3101 belong to?
      A: It belongs to Triconex Trident SIS series, different from Tricon 3101 processor module.

• 3. Q: What safety standard does Triconex MP3101 comply with?
      A: It meets IEC 61508 standard and obtains SIL3 safety certification for safety-critical industrial applications.
