GE VMIVME1150 64-Channel Opto-Isolated Digital Input Board

GE VMIVME1150 is a double-height VMEbus optically isolated digital input board developed by VMIC (GE Intelligent Platforms). It provides 64 isolated digital input channels, designed to collect contact status and switching signals in industrial VME control systems, with excellent noise suppression for harsh industrial environments.

This board adopts high voltage optical isolation design, supports configurable input filtering and logic polarity. It is widely used in GE turbine control, industrial simulation and heavy-duty process control racks, and it is a classic discontinued maintenance spare part for VME I/O systems.

Data Parameters

• 1. Brand: GE (VMIC)

• 2. Model: VMIVME1150

• 3. Product Type: 64-Channel Opto-Isolated DI VME Board

• 4. Application: VMEbus rack, turbine & industrial real-time control system

• 5. Feature: 64 channels, 1kV continuous isolation, 7.5kV pulse withstand

• 6. Characteristic: 5–48VDC input range, configurable filter & logic level

• 7. Bus Interface: VMEbus A16/A24, D08/D16 data transfer

• 8. Form Factor: 6U double height Eurocard

• 9. Connector: Dual front panel I/O terminals

• 10. Operating Temperature: -20℃ ~ +60℃

Core Functions

• 1. Collect on-site dry contact and DC switching status signals through opto-isolation.

• 2. Suppress external electrical interference to protect the backplane and host CPU.

• 3. Support positive/negative logic selection and input noise filtering configuration.

• 4. Transmit channel status data to VME master controller via VME bus.

• 5. Monitor switch feedback signals for interlock and sequence control logic.

Application Scenarios

• 1. GE gas/steam turbine VME control cabinet signal acquisition rack.

• 2. Industrial simulation equipment and real-time test system I/O collection.

• 3. Heavy industry old VME platform overhaul and spare replacement.

• 4. Power generation equipment interlock status monitoring system.

• 5. Legacy VMIC VME digital input spare parts inventory backup.

FAQ

• 1. Q: What is GE VMIVME1150?
      A: It is a 64-channel optically isolated digital input VME board for VMIC VME systems.

• 2. Q: What is the isolation rating?
      A: 1000V continuous isolation, 7500V transient pulse withstand voltage.

• 3. Q: Can it work with non-VME controllers?
      A: No, it must be installed in a standard VME backplane rack with VME master CPU.
