Bently Nevada 3500/93 135785-01 Display Module

Bently Nevada 3500/93 135785-01 is the system display module for the 3500 machinery monitoring system. It connects to the 3500 rack backplane to read vibration, speed and displacement monitoring data from each monitoring module.

This front panel unit supports local data viewing, alarm checking and simple parameter setup on site. It is widely deployed on turbine and compressor monitoring racks for power, petrochemical and oil & gas industry spare replacement.

Data Parameters

• 1. Brand: Bently Nevada.

• 2. Model: 3500/93 135785-01.

• 3. Product Type: Local Display Module / Front Display Panel.

• 4. Application: Bently 3500 machinery condition monitoring rack.

• 5. Feature: Local real-time data display and alarm indication.

• 6. Characteristic: Key operation for local rack configuration checking.

• 7. Communication: Internal backplane bus with 3500 rack.

• 8. Package: Original front display assembly with keypad.

• 9. Mounting: Front slot of standard 3500 rack.

• 10. Operating Temperature: 0℃ ~ +60℃.

Core Functions

• 1. Real-time display vibration, speed, gap and temperature values of rotating equipment.

• 2. Visual alarm status indication for alert and danger threshold.

• 3. Local browsing of module configuration and channel fault information.

• 4. On-site quick check without connecting external software.

• 5. Synchronize rack event and alarm log information.

Application Scenarios

• 1. Steam turbine, gas turbine and centrifugal compressor monitoring cabinet.

• 2. Petrochemical and oil refinery rotating machinery protection system.

• 3. Power plant generator and auxiliary equipment vibration monitoring rack.

• 4. Bently 3500 system maintenance and spare parts replacement project.

• 5. Machinery protection spare inventory backup for rotating equipment.

FAQ

• 1. Q: What is Bently Nevada 3500/93 135785-01?
      A: It is the local display panel module dedicated for Bently 3500 monitoring rack.

• 2. Q: Can it modify full configuration?
      A: It supports local viewing and simple operation, full configuration needs software.

• 3. Q: Does the rack work without this display?
      A: The monitoring rack can keep running normally without the display module.
