GE 531X309SPCAJG1 Processor Board in stock

GE 531X309SPCAJG1 is a signal processor board for GE DC2000 drive and EX2000 excitation system. It handles encoder and tachometer speed feedback, current and voltage reference signal conditioning, and serves as the signal interface matched with SDCC main control card.

This legacy circuit board is discontinued. It is widely used as spare parts for heavy-duty DC drive and generator excitation cabinet overhaul, with potentiometers and DIP switches for gain adjustment and signal configuration.

Data Parameters

• 1. Brand: GE (General Electric / GE Vernova)

• 2. Model: 531X309SPCAJG1

• 3. Product Type: Signal Processor Board (SPC)

• 4. Application: DC2000 drive / EX2000 generator excitation system

• 5. Feature: Encoder & tachometer input, 3 current ref + 1 voltage ref processing

• 6. Characteristic: Onboard potentiometers, DIP switches for gain and filter setting

• 7. Communication: RS422 serial port, LAN internal bus

• 8. Compatible Devices: SDCC drive control card, NTB terminal boards

• 9. Mounting: Installed inside drive or excitation cabinet rack slot

• 10. Operating Temperature: -20℃ ~ +70℃

Core Functions

• 1. Collect speed feedback signals from encoder and tachometer.

• 2. Condition and convert current and voltage reference signals for main controller.

• 3. Transmit processed signal data to SDCC card via LAN internal bus.

• 4. Support RS422 serial communication for parameter debugging and diagnosis.

• 5. Adjust signal gain and filter parameters by onboard potentiometers and switches.

Application Scenarios

• 1. Power plant EX2000 generator excitation control cabinet.

• 2. Steel rolling mill large DC drive speed regulation system.

• 3. Heavy industrial DC variable speed drive and tension control equipment.

• 4. Turbine excitation speed feedback and analog signal conditioning unit.

• 5. Old GE DC2000 / EX2000 system spare replacement and renovation.

FAQ

• 1. Q: What is GE 531X309SPCAJG1?
      A: It is SPC signal processor board for GE DC2000 drive and EX2000 excitation system.

• 2. Q: Does it need to cooperate with SDCC card?
      A: Yes, it must work together with SDCC main control card to realize closed-loop speed regulation.

• 3. Q: Is this model still in production?
      A: It has been discontinued, only available for aftermarket spare supply.
