ABB UFC762AE101 3BHE006412R0101 DCS Control Board Module in stock
ABB UFC762AE101 3BHE006412R0101 is a rack-mounted control board designed for ABB AC800F Freelance DCS system. It undertakes core control logic operation and realizes high-speed data interaction between the controller and field I/O modules through the backplane bus.
This control board integrates multi-channel signal processing circuit and diagnostic LED indicators. It is a discontinued legacy spare part, widely used for maintenance replacement of old power and chemical plant distributed control systems.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | ABB |
| 2 | Model | UFC762AE101, 3BHE006412R0101 |
| 3 | Module Type | DCS Control Board Module |
| 4 | Compatible System | ABB AC800F Freelance DCS |
| 5 | Power Supply | 24VDC |
| 6 | Operating Temperature | 0 ~ +60°C |
| 7 | Status | Discontinued legacy spare part |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Execute core control logic and process field collected analog and digital signals |
| 2 | Carry out high-speed backplane bus communication within the DCS rack |
| 3 | Coordinate data exchange between controller and I/O modules |
| 4 | Onboard LED indicators for power, running status and fault diagnosis |
| 5 | Built-in watchdog circuit to guarantee stable operation under industrial interference |
Application Scenarios
| No. | Application |
|---|---|
| 1 | ABB AC800F Freelance DCS distributed control rack system |
| 2 | Thermal power plant process monitoring and control system |
| 3 | Petrochemical and chemical production automation control |
| 4 | Legacy industrial DCS spare replacement and system retrofit |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q: What is ABB UFC762AE101 3BHE006412R0101? A: It is ABB control board for AC800F Freelance DCS, responsible for core logic operation and rack bus communication. |
| 2 | Q: Which DCS system can this board work with? A: It is specially designed for ABB AC800F Freelance DCS platform. |
| 3 | Q: Is this module still in production? A: This model has been discontinued, only surplus or used spare parts available for maintenance. |
