ABB GRBTU 3BSE013175R1 Gateway Base Terminal Unit in stock

ABB GRBTU 3BSE013175R1 is a dedicated gateway base terminal unit matched with ABB GOP2 G2010A 10.4ST operator panel under System 800xA DCS platform. It is installed on the back of HMI panel to provide wiring terminals, power distribution and bus signal transmission channel.

This terminal base integrates 24VDC power terminal and Ethernet communication terminal, realizing stable connection between GOP2 touch screen and 800xA control network. It adopts cabinet rear mounting design and serves as spare replacement part for DCS control room HMI maintenance and retrofit projects.

Data Parameters

• 1. Brand: ABB.

• 2. Model: GRBTU, Part No:3BSE013175R1.

• 3. Product Type: HMI Gateway Base Terminal Unit.

• 4. Matched HMI: GOP2 G2010A 10.4ST operator panel.

• 5. Applicable System: ABB System 800xA DCS.

• 6. Power Terminal: 24V DC power input interface.

• 7. Communication: Ethernet terminal for 800xA control network.

• 8. Mounting: Panel rear installation, share panel cutout with HMI.

• 9. Operating Temperature: 0℃ ~ +50℃.

• 10. Weight: Approximately 1.1kg.

Core Functions

• 1. Provide reliable terminal blocks for power cable and network cable wiring of GOP2 HMI panel.

• 2. Complete power distribution and signal routing between 800xA DCS network and operator panel.

• 3. Internal bus circuit transmits real-time process data and alarm information to GOP2 touch screen.

• 4. Adopt screw-type safety terminals to prevent loose wiring caused by equipment vibration.

• 5. Support quick disassembly for convenient on-site maintenance and spare part replacement.

Application Scenarios

• 1. Power plant DCS control room GOP2 operator panel installation and spare replacement.

• 2. Petrochemical plant 800xA distributed control system cabinet renovation project.

• 3. Metallurgy, pulp and paper industry automation HMI terminal wiring base.

• 4. Offshore platform and marine control cabinet human-machine interface assembly.

• 5. Old ABB 800xA system upgrade and HMI base fault replacement.

FAQ

• 1. Q: What is ABB GRBTU 3BSE013175R1?
      A: It is a gateway base terminal unit specially used for ABB GOP2 HMI panel in System800xA DCS system, responsible for wiring and signal transmission.

• 2. Q: Which HMI panel is GRBTU compatible with?
      A: It is specially matched with GOP2 G2010A 10.4ST 10.4-inch industrial touch operator panel.

• 3. Q: Where is this terminal base installed?
      A: It is mounted on the back of the control cabinet panel and shares the same opening with the GOP2 touch screen.
