ABB CI855K01 3BSE018106R1 MasterBus300 Communication Interface Module

ABB CI855K01 (Part Number: 3BSE018106R1) is a communication interface module developed for ABB AC 800M controller. It adopts MasterBus 300 communication protocol to realize high-speed data interaction between AC800M and legacy Advant control systems.

This module is equipped with dual Ethernet ports to support network redundancy design. It is widely used as spare parts for DCS system upgrade, cabinet retrofit and emergency replacement in petrochemical, power and pulp & paper industries.

Data Parameters

• 1. Brand: ABB.

• 2. Model: CI855K01.

• 3. Part No: 3BSE018106R1.

• 4. Product Type: MasterBus300 Communication Interface Module.

• 5. Compatible Controller: AC 800M series controller.

• 6. Communication Protocol: MasterBus 300 (MB300).

• 7. Communication Speed: 10 Mbit/s.

• 8. Port Configuration: Dual Ethernet ports for redundancy.

• 9. Mounting Method: Rack mount in AC800M controller cabinet.

• 10. Application Environment: Industrial DCS control cabinet.

Core Functions

• 1. Realizes high-speed data transmission between AC800M and old Advant DCS systems.

• 2. Supports network redundancy to improve communication reliability of control network.

• 3. Enables seamless system integration and smooth migration of legacy control systems.

• 4. Transmits real-time control variables and status signals between different control racks.

• 5. Supports firmware download and configuration through Control Builder software.

Application Scenarios

• 1. Power plant DCS control system transformation and upgrade.

• 2. Petrochemical industry distributed control system reconstruction.

• 3. Pulp and paper factory legacy Advant control system integration.

• 4. ABB AC800M control cabinet maintenance and spare parts replacement.

• 5. Hybrid operation of new and old generation ABB control systems.

FAQ

• 1. Q: What is ABB CI855K01 3BSE018106R1 used for?
      A: ABB CI855K01 is a MasterBus300 communication interface module for AC800M controller. It connects the new AC800M controller with legacy Advant DCS systems for data exchange.

• 2. Q: What communication protocol does CI855K01 adopt?
      A: It uses MasterBus 300 (MB300) protocol, which is dedicated for ABB legacy DCS interconnection.

• 3. Q: Does CI855K01 support redundant communication?
      A: Yes. It has two Ethernet ports and supports network redundancy to prevent single point of communication failure.
